KitchenAid Dishwasher Stops Mid Cycle – Why And How To Fix It?

When you are a dishwasher user, you may know how a dishwasher will save your time, water, and effort. But if it stops working, it can be big trouble for you to clean all the utensils. So, how to fix it, when my KitchenAid dishwasher stops mid cycle?

The dishwasher may stop mid cycle because of having a loose door latch, problems with thermal fuse, may the dishwasher fan or vent have issues or more. According to the problem, you need to replace the thermal fuse, vent, and fan assembly or replace the door latch and others to fix.

Today I’ve come up with the reason why your dishwasher stopped working mid-cycle and how you can fix them easily. So why are you waiting? Let’s get started!

No products found.

Why Does Your Dishwasher Stop Mid Cycle?

When your KitchenAid dishwasher stops mid-cycle, there is always an issue that you need to detect and resolve. A few reasons can cause your dishwasher to shut off. Sometimes, you may have a problem with the door latch assembly.

The door latch may get loose during the cycle, or the switch may deactivate. A blown fuse is one of the most common causes of the dishwasher quitting while in operation.

If you can’t find the cause of your problem, and it’s not a blown fuse, try inspecting a thermal fuse. This little device will cut off the power if it gets too hot inside the dishwasher.

If your dishwasher does not have enough water pressure or may shut off on outage, the dishwasher may stop working. You may also have a defective control board in your dishwasher, which may cause stopping mid cycle and so on. If you do not find any reason, inform the maintenance service.

What Do You Do When Your Dishwasher Stops Mid Cycle?

If you identify why your dishwasher stops mid cycling, it will be easy for you to fix it up. You’ve probably already done some KitchenAid dishwasher troubleshooting and found the source of the problem. Now here are the ways how to fix your dishwasher at home.

Fix The Faulty Door Latch Issue

Your KitchenAid dishwasher will not complete a cycle if the door latch is broken. The latch provides a safety feature, preventing your utensils from dropping out.

It has a microswitch that keeps the door in place during the procedure.
You can test the microswitch by manually activating it.

If the door latch and switch are working properly, then OK. If this causes trouble, the door will not close and latch in place.

You’ll need to replace it to fix the problem in most cases. It’s best to recommend hiring a professional technician to complete this task for you.

Thermal Fuse Fixing

Maintaining the dishwasher is important to get the appropriate power for each cycle. The dishwashers use a series of fuses. If your dishwasher won’t start at all, or if it has started but then stopped, a blown fuse could be a cause.

When your dishwasher stops working suddenly, you may have a thermal fuse problem. Because when the temperature is very hot, the fuse will cut the power to the circuit board to prevent danger.

When the fuse is burnt, your dishwasher mid cycle may stop working. After replacement of the thermal fuse, fix this issue.

Analysis of the Electronic Control Board’s Connection

On the dishwasher’s electronic control board, there are a lot of connections. When the dishwasher does not drain the water, there may be a problem with the electronic board.

Your dishwasher’s control panel starts the wash motor, opens the door for drying, and locks out some function buttons. So, you don’t change settings accidentally.

The most common problems with mid cycle spotting occur when there is a power supply or if there is not enough water pressure to operate.

If your power supply circuit boards broke or malfunction, you’ll have to spend time and money fixing them or replacing them.

Check The Vent And Fan Assembly

Even though your dishwasher might have finished the wash cycle, it might not have completed the drying cycle. If you find that your dishwasher did faster than you thought, it might be because it is skipping the drying cycle.

When you open your dishwasher, your dishes will still be wet. If you use a dry cycle, you’ll want to look at the fan parts. When the fan doesn’t work, it won’t be able to get rid of the hot, wet air that’s left after a wash cycle.

If you find that things are very cold inside, you’ll need to check this with a multimeter. You can open vents to remove hot air and moisture from the dishwasher when the drying cycle begins.

During a cycle, the dishwasher will stop if its fan fails. Either the fan or the vent will need to replace if they stop working.

It may be possible that the other parts could break if your dishwasher turns off mid cycle and only stops the dry cycle, but the fan is still running.

Another thing you need to investigate is the high-limit thermostat. It turns off the heater to ensure that the dishwasher doesn’t get too hot.

Faulty Heating Element

The first phase of the standard dishwashing program for kitchen appliances requires enough water. When you finish listening to this filling process, you should check whether your appliance repair needs while the problem continues or stops.

You could also pause the wash, slightly open the door and rule out whether your dishwasher does heat the water or not. If it is not working, you must replace it.

The heating element oversees keeping the dishwasher tub warm, which aids in cleaning and drying your dishes simultaneously.

Make a visual inspection of your heating element if the machine stops mid-cycle. The heating circuit should check for faulty wiring, problems with the control settings, or a blown fuse.

Need Visual Inspection and Clean The Circulation Pump

Check your dishwasher for obstructions, especially in the bottom rack. If there is a large amount of food left on dishes or utensils, it could visually affect how your dishwasher functions.

Cleaning the circulation drain pump when the dishwasher is not filling water. It is a simple operation, but you must carry it out with due precautions. First, recommend that you turn off the power.

Locate the circulation pump and thoroughly clean it of any dirt accumulated. You should undoubtedly get a new one if you see damage to your circulation pump motors when cleaning.

At A Glance! Best Dishwasher For Smooth Work

No products found.

How Do I Run a Diagnostic Test On My KitchenAid Dishwasher?

Dishwashers are expensive items that you will want to keep running for as long as possible. But for that to happen, it’s important to make sure your dishwasher is in good working order.

Your dishwasher doesn’t need a lot of attention, but at some point, to run a diagnostic cycle test on your KitchenAid dishwasher, follow the procedures below. Turn off the water supply to your dishwasher.

Shut off the power to your dishwasher, unplug the unit, and pull out the plug. You should now be able to open your dishwasher door. Turn on the main electrical switch for your unit.

If you want to run a full diagnostic test on your dishwasher, go ahead and put several full loads of dishes through it. If not, skip this step and move on to the next one.

When running diagnostics on Kitchenaid, you must hit the keys “Heated Dry” and “Normal” twice, but only in the order mentioned. It should note that tests will either abort error codes will display if there is a problem.

Search in Google the error code to find out what it implies. You may now Google its meaning and a possible DIY cure instead.

You might want to try a single test, for now, to be sure it’s working properly. Once you’ve identified a problem with your dishwasher, you can fix it yourself. To test this, disassemble the dishwasher and clean every part inside.

You should remove in-door racks and wash away any dirt or food residue before starting the wash cycle again.

Is There A Reset Button On KitchenAid Dishwasher?

Actually, you don’t get any rest button directly in the KitchenAid dishwasher, but you can do ‘Reset” manually., there is a ‘Cancel’ button and you can use it as a reset button.

If the dishwasher doesn’t start a cycle, try to press the start button a couple of times for 15 to 30 seconds. Due to pressing, lights may flash and beep continuously.

Then hold down the start button for three seconds or until you hear a beep will reset most dishwashers. If it doesn’t start, you can use the keypad buttons to determine what’s wrong with the dishwasher.

You can cancel and resume a wash cycle in a KitchenAid dishwasher. The Cancel or reset button is normally found on the control panel area.

When is the KitchenAid dishwasher not working properly, you are informed of unique terminology for each brand and model.

How To Add Dishes To The KitchenAid Dishwasher After The Cycle Has Started?

Some people like to load their dishwashers before the cycle of the KitchenAid dishwasher starts and stops. It will assist you in saving space and prevent food from sticking to dishes that have been in soap for a long period.

It doesn’t matter when you add an item to the normal wash. There is no time limit on when you can do this. To check the soap dispenser, you should open the door and look inside it.

When the cover close, you can add things. You can’t add the item when the soap dispenser door is open, so you can’t. It should go into the next load.

Lift the door latch to stop it. Wait for the spraying to stop before opening the door. When the cycle pauses, all the process and option lights turn on. Even if the soap dispenser lid is closed, add it.

FAQ: Frequently Asked Questions

How Do I Reset My KitchenAid Dishwasher?

Sometimes, you might have a small electrical problem with the dishwasher not cycling. Take the steps below to reset your KitchenAid Dishwasher effortlessly. Please Turn off the circuit breakers.

After using the dishwasher, turn off the power and unplug the cord. Wait 5 minutes before going on. Reconnect the dishwasher’s power supply and restart it. Then turn the circuit breaker “on” and turn on your dishwasher.

How To Read Error Codes for KitchenAid?

Error codes display on digital control panels. These error code definitions can help you troubleshoot your KitchenAid dishwasher. Enter your dishwasher model number to find a complete parts list for your dishwasher.

On devices without a digital display panel, the Clean light washes in a pattern that indicates the problem. The LED lights flash the Function code first, then the Problem code 2 seconds later.

For example, 6 lights followed by 1 flash (6-1) means the “electronic control lock feature does not detect water entering the dishwasher tub.” After a 5-second delay, the light repeats.

How Do I Test My KitchenAid Dishwasher Control Panel?

Depending on the model, follow the steps below to perform a diagnostic cycle test on your KitchenAid dishwasher control panel. This is the most common method I will share with you:

This sequence can be found on the control panel:

Heat Dry, Temperature, Rinse

The display will light up once you press the toggles. Go ahead and push the start button, a test cycle will begin. It will also command the dishwasher to complete all its functions.

Press The Following Sequence on The Control Panel:

1, 2, 3. The same again, And the same once more. After pressing the sequence, go ahead and push the start button. This process will light up the panel. For this procedure, your dishwasher runs a diagnostic for you.

If an error code is detected, the control panel of the KitchenAid dishwasher will display it. You can now proceed with the troubleshooting methods. It will vary based on the model.

How Do I Start My Dishwasher?

Firstly, your dishwasher should fill with dishes. Then add a little Detergent to the mix. Select Your cycle of Choice. While selecting, an indicator light will illuminate. Choose the option you desire.

When the option is selected, the indicator lights will illuminate. Ensure the water is warm or hot from the nearest hot water tap to get the most out of your dishwasher. The faucet should shut off.

Now press the Start or Cancel button on the display panel to get things going. When you’re done closing the door, make sure it’s latched.

How To Replace A Dishwasher Heating Element?

Before replacing the heating element, it would help disconnect the dishwasher from the main power and water supply. Now unscrew both the toe panel and front access panels. Pull the dishwasher out.

Finally, remove the heating element and Set up a new heating element. Put the dishwasher back together. And restore the water and electricity.

How To Replace A Dishwasher Electronic Control Board?

Replacing a control board is very simple. First, turn off the power to the dishwasher at the circuit breaker. Next, find the water level switch connector on the dishwasher body and shut it off using a small screwdriver or hex key.

Then, removing the door panel and the control panel is necessary. Unplug and remove the electronic control panel. Finally, the new should install the electronic control board.

Final Thoughts of KitchenAid Dishwasher Stops Mid Cycle?

When your dishwasher not finishing the cycle, you can do a few things to troubleshoot the problem.

It may have a problem with your lid switch assembly, power supply, motor assembly, or water inlet valve, and that’s why may your Kitchenaid dishwasher stops mid-cycle.

You should find the reason first, then act according to the problem. Our step guides on diagnosing and troubleshooting the KitchenAid dishwasher may help you to fix the issues with your dishwasher.

It is the quickest and most cost-effective way to identify and correct minor issues before they become major issues.

If those don’t work, you may need to call an appliance technician. Keep in mind that dishwashers do malfunction from time to time. So, don’t be desperate if it happens to you. Stay safe and have a happy dishwashing experience!
